7
NXDN™ OPERATION
7-21
The Over The Air Programming (OTAP) function
enables wireless programming using a transceiver�
Up until now, you needed programming software, a
PC, and a data cable to program transceivers� As the
number of transceivers in a system increased, the
programming cost was higher and it took more time
to program�
This function provides easier and faster programming,
and lowers the cost�
TIP: See the optional CS-OTPM1 otap manager
software Help le or its instruction manual for
details�
NOTE: When using the OTAP function, the following
settings are required in the optional CS-F52D
programming software�
For the OTAP Management transceiver:
• Set Connection Speed to “19200�”
• Set Mode to “PC CMD V2�”
( Common > External I/O > Port Setting >
Multi-Connector)
For the SU:
Set OTAP Accept to “ON�”
(Digital > OTAP > OTAP Setting > OTAP Accept)
PC
(The CS-OTPM1
is installed)
OTAP Management
Transceiver
Repeater
Internet
L You can also remotely program through repeaters
or the Internet�
ICF le
OTAP
data
SU
SU
SU
* SU= Subscriber Unit
Over The Air Programming (OTAP) function
