Icom IC-F52D User Manual

3
BASIC OPERATION
3-6
D Selecting a RAN channel
(Menu > Channel/Scan > RAN CH Select)
1� While in the Digital mode, push [Menu] to display
the “Menu” screen.
2� Push [P2 (Up)] or [P1 (Down)] to select “Channel/
Scan,” then push [OK]�
Channel/Scan ►
Signaling/Call ►
Menu
3� Push [P2 (Up)] or [P1 (Down)] to select “RAN CH
Sel,” then push [OK]�
RAN CH Sel ►
RF Power ►
Channel/Scan
4� Push [P2 (Up)] or [P1 (Down)] to select a RAN
channel, then push [OK].
✔ 1
✔ 2
RAN CH Sel
RAN CH Sel
2
• The selected RAN channel is briey displayed and set.
5� Hold down [Back] for 1 second to return to the
standby screen�
TIP: While in the Digital mode, push
[Tone/RAN CH Select] to directly display the “RAN
CH Sel” screen in step 4 above�
Selecting a channel (Continued)

Icom IC-F52D Specifications

General

Brand	Icom
Model	IC-F52D
Category	Transceiver
Language	English
