Page 118 Operation Manual
E.3 Dimensions and Weight
Scanner outer dimensions, book cradle closed 1100 x 880 x 855 mm (H x W x D)
43.3 x 34.6 x 33.7 inch
Scanner outer dimensions, book cradle opened 1100 x 1000 x 855 mm (H x W x D)
43.3 x 39.4 x 33.7 inch
Total weight of scanner, ready to use Approx. 77 kg / 170 lbs.
Transport Box:
Dimensions Transport Box
(contains complete scanner on wooden drawer)
1270 x 1030 x 1020 mm (H x W x D)
50 x 40.6 x 40.2 inch
Weight Transport Box: 73 kg / 161 lbs.
Total shipping weight:
Total shipping weight 150 kg / 331 lbs.
E.4 Ambient Conditions
Operating Temperature 5 to 40 °C / 40 to 105 °F
Storage Temperature 0 to +60 °C / 32 to 140 °F
Relative Humidity 20 to 80% (non-condensing)
Ambient luminance ≤ 300 Lux
Noise Level ≤ 42 dB(A) (Operating)
≤ 33 dB(A) (Standby)
