Page 30 Operation Manual
A.9.1 Starting the
Push the illuminated “Power” button to start the scanner.
Picture 4: Keyboard with Power button
The button illumination changes to blue.
The scanner starts with self-test routines and verifies all system components. Status
messages will be displayed on the TFT flat screen and on the WVGA color touchscreen.
At the end of the start-up sequence, the touchscreen displays the start screen.
A.9.2 Switching the
to Standby Mode
Always use the “Power” button to switch the scanner to
standby mode.
Press and hold the power button for at least three seconds. While pressing the button, a
“click” sound is audible.
During the shut-down sequence the TFT flat screen and the touchscreen show the
scanner name and version and a progress bar.
The power down sequence will take a few seconds.
Finally the TFT flat screen and the touchscreen switch off and the “Power” button will be
illuminated red.
Power button
