B.5.2.2 Operation Info Screen
In the section Information the button Operation Info opens the following list.
It shows various scan counters and elapsed time described in the following table.
Picture 108: Operation Info screen
The following table gives a brief description.
Field Description
The total number of scans performed since the scanner left
the factory. Each CCD scan cycle is counted, regardless of
it being a pre-scan or a full scan.
The total number of power up cycles performed since the
scanner left the factory. This function counts the start/stop
button invoked cycles only.
The total operating time since the scanner left the factory.
This is the on-time only, standby time does not count.
The total lamp operating time since the scanner left the
factory. This is the on-time including the dimme
periods.
Time
The typical remaining lifetime of the lamps. The lifetime of
the lamps of the WideTEK 36 scanner is so long, that they
last under normal work conditions
for the complete lifetime
of the device.
To return to the USER screen (Picture 106) click the button Back to Main Menu or click
on the “Return” button in your browser.
Click the button Launch Scan Application to switch directly to the main screen of the
integrated S2N user interface.
