D Technical Data
D.1 Scanner Specifications
Optical System
Maximum document width: 38 inches / 965 mm
Scan width: Max. 36 inches / 915 mm
Resolution: 1200 x 600 dpi
Sensor type: 3x Tri-Color CCD, encapsulated and dust-proof
12 bit grayscale (internal resolution)
36 bit color (internal resolution)
Sensor resolution: 68.400 pixels (3x 22.800)
Scan modes: 24 bit color, 8 bit indexed color
8 bit gray scale
1 bit Black/White
Illumination:
Light source: Two lamps with 130 white LEDs each
Warm-up time: None.
Max. brightness immediately after switch-on.
Temperature dependence: None
UV / IR emission None
Lifetime 50.000 hours scanning time
D.2 Ambient Conditions
Operating temperature +5 to +40 °C / +40 to +105 °F
Storage temperature 0 to +60 °C / +32 to +140 °F
Relative humidity 20 to 80% (non-condensing)
Noise level < 35 dB(A) (Operating)
< 25 dB(A) (Stand-by)
