8.3.2 SATA/SAS Connectors
The server board includes eight SATA/SAS connectors. On the server board, these connectors
are labeled as SATA/SAS_ 0 to SATA/SAS_7. By default, only the connector labeled
SATA/SAS_0 to SATA/SAS_3 are enabled and has support for up to four SATA ports capable
of transfer rates of up to 3Gb/s. The connector labeled SATA/SAS_4 to SATA/SAS_7 is only
enabled when an optional Intel
®
RAID C600 Upgrade Key is installed. See Table 10 for a
complete list of supported storage upgrade keys. The following tables provide the pin-out for
each connector.
Table 34. SATA/SAS Connector Pin-out (SATA/SAS_0 to SATA/SAS_7)
Pin
Signal Name
1
GND
2
SATA_TX_P
3
SATA_TX_N
4
GND
5
SATA_RX_N
6
SATA_RX_P
7
GND
8.3.3 SAS SGPIO Connectors
Table 35. SAS SGPIO Connector Pin-out (SAS_SPGIO_0 and SAS_SPGIO_1)
Pin
Signal Name
Pin#
Signal Name
1
CLOCK
2
LOAD
3
GND
4
DATAOUT
5
DATAIN
8.3.4 Intel
®
RAID C600 Upgrade Key Connector
The server board provides one connector to support Intel
®
RAID C600 Upgrade Key. The Intel
®
RAID C600 Upgrade Key is a small PCB board that enables different versions of RAID 5
software stack and/or upgrade from SATA to SAS storage functionality. On the server board,
the connector is labeled as STRO UPG KEY. The pin configuration of connector is identical and
defined in the following table.
Table 36. Intel
®
RAID C600 Upgrade Key Connector Pin-out (STRO UPG KEY)
Pin
Signal Name
1
GND
2
FM_PBG_DYN_SKU_KEY
3
GND
4
FM_SSB_SAS_SATA_RAID_KEY
8.3.5 HSBP_I2C Header
Table 37. HSBP_I2C Header Pin-out (HSBP_I2C)
Pin
Signal Name
1
SMB_HSBP_3V3STBY_DATA
2
GND
