Intel® Server Board S2600CO Family TPS Functional Architecture Overview
Revision 1.0 33
Intel order number G42278-002
3.2.3.3 Intel Riser Card Option
The server board provides support for Intel
®
Riser Card. These optional modules attach to PCIe
slot6 on the server board and are supported by x16 PCIe Gen3 signals from the IIO module of
the CPU 2 processor.
Table 8. Supported Intel
®
Riser Card
2U PCIe x16 riser, 1 slot
x16 electrical/x16 mechanical
2U PCIe x16 riser, 3 slots
one x8 electrical/x16 mechanical
Two x4 electrical/x8 mechanical
1U PCIe x16 riser, 1 slot
x16 electrical/x16 mechanical
3.2.3.4 Network Interface
Network connectivity is provided by means of an onboard Intel
®
Ethernet Controller 1350-AM4
providing up to four 10/100/1000 Mb Ethernet ports. The NIC chip is supported by implementing
x4 PCIe Gen3 signals from the IIO module of the CPU 1 processor.
On the Intel
®
Server Board S2600CO, four external 10/100/1000 Mb RJ45 Ethernet ports are
provided. Each Ethernet port drives two LEDs located on each network interface connector. The
LED at the right of the connector is the link/activity LED and indicates network connection when
on, and transmit/receive activity when blinking. The LED at the left of the connector indicates
link speed as defined in the following table.
Table 9. External RJ45 NIC Port LED Definition
LAN activity is occurring
The server board has seven MAC addresses programmed at the factory. MAC addresses are
assigned as follows:
NIC 1 MAC address (for OS usage)
NIC 2 MAC address = NIC 1 MAC address + 1 (for OS usage)
NIC 3 MAC address = NIC 1 MAC address + 2 (for OS usage)
NIC 4 MAC address = NIC 1 MAC address + 3 (for OS usage)
BMC LAN channel 1 MAC address = NIC1 MAC address + 4
BMC LAN channel 2 MAC address = NIC1 MAC address + 5
BMC LAN channel 3 (RMM) MAC address = NIC1 MAC address + 6
