8.5.2 CPU FAN Connector
The server board also provides support for two CPU cooling fans. Each 4-pin connector is
monitored and controlled by platform management. On the server board each CPU fan
connector is labeled as CPU_1FAN and CPU_2FAN. The following table provides the pin-out
for both fan connectors.
Table 50. CPU Fan Connector Pin-out (CPU_1 FAN and CPU_2 FAN)
Pin
Signal Description
1
GND
2
12V
3
TACH
4
PWM
8.6 Serial Port Connectors
The server board includes two serial port connectors.
8.6.1 Serial Port A connector (DB9)
Serial-A is an external RJ45 type connector labeled as SERIAL_A and has the following pin-out
configuration.
Table 51. Serial Port A Connector Pin-out (SERIAL_A)
Pin
Signal Name
Pin
Signal Name
1
SPA_DCD
2
SPA_SIN_N
3
SPA_OUT_N
4
SPA_DTR
5
GND
6
SPA_DSR
7
SPA_RTS
8
SPA_CTS
9
SPA_RI
8.6.2 Serial Port B Connector
Serial-B is an internal 10-pin DH-10 connector labeled as SERIAL_B and has the following pin-
out.
Table 52. Serial-B Connector Pin-out (SERIAL_B)
Pin
Signal Name
Pin
Signal Name
1
SPA_DCD
2
SPA_DSR
3
SPA_SIN_N
4
SPA_RTS
5
SPA_SOUT_N
6
SPA_CTS
7
SPA_DTR
8
SPA_RI
9
GND
8.6.3 Video Connector
The following table details the pin-out definition of the external VGA connector.
Table 53. Rear VGA Video Connector Pinout (VGA)
Pin
Signal Name
1
RED
2
GREEN
