Intel S2600CO Family User Manual

Intel® Server Board S2600CO Family TPS Power Supply Specification Guidelines
Revision 1.0
Intel order number G42278-002
109
3.3V
5.0V
12V1
12V2
12V3
-12V
5.0Vstby
Total
Power
12V
Power
3.3V/5V
Power
Load4
2.5
2
13.1
13.1
18
0
0.3
550
530
18
Load5
0.5
0.3
15
15
6.5
0.5
3
462
438
3
Load6
16
4
1
1
3.5
0
0.3
140
66
73
Load7
16
13
1
1
9
0.5
3
271
132
118
12.1.3 Standby Output
The 5VSB output is present when an AC input greater than the power supply turn on voltage is
applied.
12.1.3.1 Voltage Regulation
The power supply output voltages stay within the following voltage limits when operating at
steady state and dynamic loading conditions. These limits include the peak-peak ripple/noise.
These shall be measured at the output connectors.
Table 63. Voltage Regulation Limits
Parameter
Tolerance
Min
Nom
Max
Units
+3.3V
- 3%/+5%
+3.20
+3.30
+3.46
Vrms
+5V
- 4%/+5%
+4.80
+5.00
+5.25
Vrms
+12V1
- 4%/+5%
+11.52
+12.00
+12.60
Vrms
+12V2
- 4%/+5%
+11.52
+12.00
+12.60
Vrms
+12V3
- 4%/+5%
+11.52
+12.00
+12.60
Vrms
- 12V
- 10%/+10%
- 13.20
-12.00
-10.80
Vrms
+5VSB
- 4%/+5%
+4.80
+5.00
+5.25
Vrms
12.1.3.2 Dynamic Loading
The output voltages remain within limits specified for the step loading and capacitive loading
specified in the table below. The load transient repetition rate is tested between 50Hz and 5kHz
at duty cycles ranging from 10%-90%. The load transient repetition rate is only a test
specification. The  step load may occur anywhere within the MIN load to the MAX
load conditions.
Table 64. Transient Load Requirements
Output
 Step Load Size
(See note 2)
Load Slew Rate
Test capacitive Load
+3.3V
6.0A
0.5 A/sec
970 F
+5V
4.0A
0.5 A/sec
400 F
12V1+12V2+12V3
23.0A
0.5 A/sec
2200 F
1,2
+5VSB
0.5A
0.5 A/sec
20 F
Notes:
1. Step loads on each 12V output may happen simultaneously.
2. The +12V should be tested with 2200F evenly split between the four +12V rails
3. This will be tested over the range of load conditions in section 12.1.2.
12.1.3.3 Capacitive Loading
The power supply is stable and meets all requirements with the following capacitive loading
ranges.
