Intel® Server Board S2600CO Family TPS Platform Management Functional Overview
Revision 1.0 73
Intel order number G42278-002
6.10.12 SM-CLP (SM-CLP Lite)
SMASH refers to Systems Management Architecture for Server Hardware. SMASH is defined
by a suite of specifications, managed by the DMTF, that standardize the manageability
interfaces for server hardware. CLP refers to Command Line Protocol. SM-CLP is defined by
the Server Management Command Line Protocol Specification (SM-CLP) ver1.0, which is part
of the SMASH suite of specifications. The specifications and further information on SMASH can
be found at the DMTF website (http://www.dmtf.org/).
The BMC provides an embedded “lite” version of SM-CLP that is syntax-compatible but not
considered fully compliant with the DMTF standards.
The SM-CLP utilized by a remote user by connecting a remote system from one of the system
NICs. It is possible for third party management applications to create scripts using this CLP and
execute them on server to retrieve information or perform management tasks such as reboot the
server, configure events, and so on.
The BMC embedded SM-CLP feature includes the following capabilities:
 Power on/off/reset the server.
 Get the system power state.
 Clear the System Event Log (SEL).
 Get the interpreted SEL in a readable format.
 Initiate/terminate a Serial Over LAN session.
 Support “help” to provide helpful information
 Get/set the system ID LED.
 Get the system GUID
 Get/set configuration of user accounts.
 Get/set configuration of LAN parameters.
 Embedded CLP communication should support SSH connection.
 Provide current status of platform sensors including current values. Sensors include
voltage, temperature, fans, power supplies, and redundancy (power unit and fan
redundancy).
The embedded web server is supported over any system NIC port that is enabled for server
management capabilities.
6.10.13 Embeded Web Server
IBMC Base manageability provides an embedded web server and an OEM-customizable web
GUI which exposes the manageability features of the IBMC base feature set. It is supported
over all on-board NICs that have management connectivity to the IBMC as well as an optional
dedicated add-in management NIC. At least two concurrent web sessions from up to two
different users is supported.
The embedded web user interface supports strong security (authentication, encryption, and
firewall support) since it enables remote server configuration and control. The user interface
presented by the embedded web user interface shall authenticate the user before allowing a
web session to be initiated. Encryption using 128-bit SSL is supported. User authentication is
based on user id and password.
