Intel S2600CO Family User Manual

Appendix D: Intel® Server Board S2600CO Family Specific Sensors Intel® Server Board S2600CO Family TPS
Revision 1.0
Intel order number G42278-002
136
Hot-plug fan support
Supported on:
 Intel
®
Server Chassis P4208 (UPM with redundant fan 4U)
 Intel
®
Server Chassis P4216 (UPM with redundant fan 4U)
 Intel
®
Server Chassis P4308 (UPM with redundant fan 4U)
Fan redundancy support
Supported on:
 Intel
®
Server Chassis P4208 (UPM with redundant fan 4U)
 Intel
®
Server Chassis P4216 (UPM with redundant fan 4U)
 Intel
®
Server Chassis P4308 (UPM with redundant fan 4U)
Table 72. Fan Domain Definition
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
P4208/P4216/P4304/P4308
(UPM with fixed fan
4U/general SKU)
0
 SSB Temp (22h)
 BB BMC Temp (23h)
 BB MEM VR Temp (25h)
 HSBP 1 Temp (29h)
 HSBP 2 Temp (2Ah)
 Exit Air Temp (2Eh)
 LAN NIC Temp (2Fh)
 DIMM Thrm Mrgn 2 (B1h)
 DIMM Thrm Mrgn 3 (B2h)
System Fan 1(30h)
1
 BB P2 VR Temp (24h)
 BB MEM VR Temp (25h)
 HSBP 1 Temp (29h)
 HSBP 2 Temp (2Ah)
 Exit Air Temp (2Eh)
 P1 Therm Margin (74h)
 P2 Therm Margin (75h)
 DIMM Thrm Mrgn 1 (B0h)
 DIMM Thrm Mrgn 2 (B1h)
 DIMM Thrm Mrgn 3 (B2h)
 DIMM Thrm Mrgn 4 (B3h)
System Fan 2(31h)
P4208/P4216/P4308 (UPM
with fixed fan 4U/150W SKU)
0
 SSB Tem p(22h)
 BB BMC Temp (23h)
 BB MEM VR Temp (25h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp (2Ah)
 Exit Air Temp (2Eh)
 LAN NIC Temp (2Fh)
 DIMM Thrm Mrgn 2 (B1h)
 DIMM Thrm Mrgn 3 (B2h)
System Fan 1(30h)
1
 BB P2 VR Temp(24h)
 BB MEM VR Temp(25h)
System Fan 2(31h)
