On-board Connector/Header Overview Intel® Server Board S2600CO Family TPS
Revision 1.0
Intel order number G42278-002
88
8.2.2 Front Panel USB Connector
The server board includes a 10-pin connector, that when cabled, can provide up to two USB
ports to a front panel. On the server board the connector is labeled “USB5-6”. The following
table provides the connector pin-out.
Table 31. Front Panel USB Connector Pin-out (USB5-6)
Pin
Signal Name
Pin
Signal Name
1
+5V
2
+5V
3
USB_N
4
USB_N
5
USB_P
6
USB_P
7
GND
8
GND
10
8.2.3 Intel Local Control Panel Connector
The server board includes a 7-pin connector that is used when the system is configured with
Intel Local Control Panel with LCD support. On the server board this connector is labeled
LCPand is located on the front edge of the board. The following table provides the pin-out for
this connector.
Table 32. Intel Local Control Pane Connector Pin-out (LCP)
Pin
Signal Name
1
SMB_SENSOR_3V3STBY_DATA_R0
2
GROUND
3
SMB_SENSOR_3V3STBY_CLK
4
P3V3_AUX
5
FM_LCP_ENTER_N_R
6
FM_LCP_LEFT_N_R
7
FM_LCP_RIGHT_N_R
8.3 On-Board Storage Connectors
The server board provides connectors for support of several storage device options. This
section provides a functional overview and pin-out of each connector.
8.3.1 SATA Only Connectors: 6 Gbps
The server board includes two white single port SATA only connectors capable of transfer rates
of up to 6Gb/s. On the server board these connectors are labeled as SATA_0 and SATA_1. The
following table provides the pin-out for both connectors.
Table 33. SATA Only Connector Pin-out (SATA_0 and SATA_1)
Pin
Signal Name
1
GND
2
SATA_TX_P
3
SATA_TX_N
4
GND
5
SATA_RX_N
6
SATA_RX_P
7
GND
Note: As an option, SATA_0 supports vertical, high profile SATA_DOM.
