Intel S2600CO Family User Manual

Intel® Server Board S2600CO Family TPS Functional Architecture Overview
Revision 1.0 15
Intel order number G42278-002
3. Functional Architecture Overview
The architecture and design of the Intel
®
Server Board S2600CO is developed around the
integrated features and functions of the Intel
®
processor E5-2600 product family, the Intel
®
C600-A chipset, the Intel
®
Ethernet Controller I350 Quad Port 1GbE chip and the Server
Engines* Pilot-III Server Management Controller.
The following diagram provides an overview of the server board architecture, showing the
features and interconnects of each of the major sub-system components.
Intel® C600
Series
Chipse
(w/ Dynamic SKU’ing)
HSBP
Integrated
BMC
LPC (33MHz)
USB 2.0 (480Mbs)
SMBUS PORTS
NC-SI PORT 1 (RMII) 100Mbps
NC-SI PORT 0 (RGMII)
VIDEO RGB
RMM4 Dedicated NIC
Module Conn
SERIAL PORT 1
2x5 HDR
USB 2.0
Zepher Conn
TPM Conn
SATA
SATA
3Gps
3Gps
3Gps
6Gps
4 USB 2.0 EXT
4 SATA 3G
Upgradable to
8 SATA/SAS 6G
ODD
Intel®
Ethernet
Controller
I350
Dual 1Gb LAN
Dual GbDual Gb
Dual 1Gb LAN
Dual GbDual Gb
SERIAL PORT 0
USB 2.0
2 USB 2.0 INT
PCIe Gen1 x1
DRAM
16MB iBMC
SPI Flash
DRAM
8MB BIOS
SPI Flash
DRAM
128MB
DDR3
SCU[7:4]
USB2.0
SCU[3:0] P[5:2] P[1:0]
LHSRHS
USB2.0
Type-A
INT
Conn
USB[7,6,5,1]
USB[13,11]
USB[0]
USB[2]
USB 1.1 (12Mbs)
USB[10]
USB[3]
SATA/SAS
SATA/SAS
SATA/SAS
SATA/SAS
SATA/SAS
SATA/SAS
SATA/SAS
SATA/SAS
Intel® Xeon®
E5-2600
CPU 1
DDR3 MEMORY
(1066/1333/1666Mhz)
CHANNEL 0
Intel® Xeon®
E5-2600
CPU 2
CHANNEL 1
CHANNEL 2
CHANNEL 3
CHANNEL 0
CHANNEL 1
CHANNEL 2
CHANNEL 3
Slot 2: x16 Conn
Slot 1 x8 Conn
DDR3 MEMORY
(1066/1333/1666Mhz)
Slot 3: x16 Conn
Supports:
UDIMM/RDIMM QRx4 (1.5V)
LV-DIMMs (1.35V)
LR-DIMMs
Copper Pass Romley-EP Pedestal Server System
Architecture Diagram
DMI2 PCIe Gen2 x4 (4GB/s)
QPI Port 1 8.0GT/s
QPI Port 0 8.0GT/s
P2 P1P3P0
IOU0 IOU2IOU1
P1P3 P2P0
IOU2IOU1 IOU0
PCIe Gen3 x16 (32GB/s)
PCIe Gen3 x16 (32GB/s)
PCIe Gen3 x4 (8GB/s)
Slot 5: x16 Conn
Slot 4: x8 Conn
Slot 6 x16 Conn
PCIe Gen3 x4 (8GB/s)
PCIe Gen3 x4 (8GB/s)
PCIe Gen3 x16 (32GB/s)
PCIe Gen3 x16 (32GB/s)
PCIe Gen3 x8 (16GB/s)
PCIe Gen1 x1 1394b INT
1394b INT
LSI
FW643E-02
11x11
3port 1394b
PCIe Gen3 x4 (8GB/s)
PCIe Gen2 x4 (4GB/s)
Figure 10. Intel
®
Server Board S2600CO Functional Block Diagram
