Platform Management Functional Overview Intel® Server Board S2600CO Family TPS
72 Revision 1.0
Intel order number G42278-002
Event Filter Number
Offset Mask
Events
6
Uncorrectable ECC
BIOS
7
POST error
BIOS: POST code error
8
FRB2
Watchdog Timer expiration for FRB2
9
Policy Correction Time
Node Manager
10
Power down, power cycle, and reset
Watchdog timer
11
OEM system boot event
System restart (reboot)
12
Drive Failure, Predicated Failure
Hot Swap Controller
Additionally, the BMC supports the following PEF actions:
 Power off
 Power cycle
 Reset
 OEM action
 Alerts
The “Diagnostic interrupt” action is not supported.
6.10.10 LAN Alterting
The BMC supports sending embedded LAN alerts, called SNMP PET (Platform Event traps),
and SMTP email alerts.
The BMC supports a minimum of four LAN alert destinations.
6.10.10.1 SNMP Platform Event Traps (PETs)
This feature enables a target system to send SNMP traps to a designated IP address by means
of LAN. These alerts are formatted per the Intelligent Platform Management Interface
Specification Second Generation v2.0. A Module Information Block (MIB) file associated with
the traps is provided with the BMC firmware to facilitate interpretation of the traps by external
software. The format of the MIB file is covered under RFC 2578.
6.10.11 Altert Policy Table
Associated with each PEF entry is an alert policy that determines which IPMI channel the alert
is to be sent. There is a maximum of 20 alert policy entries. There are no pre-configured entries
in the alert policy table because the destination types and alerts may vary by user. Each entry in
the alert policy table contains four bytes for a maximum table size of 80 bytes.
6.10.11.1 E-mail Alerting
The Embedded Email Alerting feature allows the user to receive e-mails alerts indicating issues
with the server. This allows e-mail alerting in an OS-absent (for example, Pre-OS and OS-Hung)
situation. This feature provides support for sending e-mail by means of SMTP
