Intel® Server Board S2600CO Family TPS On-board Connector/Header Overview
Revision 1.0
Intel order number G42278-002
91
Table 41. RMM4_Lite Connector Pin-out (RMM4_Lite)
Pin
Signal Name
Pin
Signal Name
1
P3V3_AUX
2
SPI_IBMC_BK_DI
4
SPI_IBMC_BK_CLK
5
SPI_IBMC_BK_DO
6
GND
7
SPI_IBMC_BK_CS_N
8
GND
8.4.2 RMM4_NIC connector
Table 42. RMM4_NIC Connector Pin-out (RMM4_NIC)
Pin
Signal Name
Pin
Signal Name
1
3V3_AUX
2
MDIO
3
3V3_AUX
4
MDC
5
GND
6
TXD_0
7
GND
8
TXD_1
9
GND
10
TXD_2
11
GND
12
TXD_3
13
GND
14
TX_CTL
15
GND
16
RX_CTL
17
GND
18
RXD_0
19
GND
20
RXD_1
21
GND
22
RXD_2
23
GND
24
RXD_3
25
GND
26
TX_CLK
27
GND
28
RX_CLK
29
GND
30
PRESENT#
8.4.3 TPM Connector
Table 43. TPM Connector Pin-out (TPM)
Pin
Signal Name
Pin
Signal Name
2
LPC_LAD<1>
3
LPC_LAD<0>
4
GND
5
IRQ_SERIAL
6
LPC_FRAME_N
7
P3V3
8
GND
9
RST_IBMC_NIC_N_R2
10
CLK_33M_TPM
11
LPC_LAD<3>
12
GND
13
GND
14
LPC_LAD<2>
8.4.4 PMBUS Connector
Table 44. PMBUS Connector Pin-out (SMB_PMBUS)
Pin
Signal Name
1
SMB_PMBUS_CLK_R
2
SMB_PMBUS_DATA_R
3
IRQ_SML1_PMBUS_ALERT_RC_N
4
GND
5
P3V3
8.4.5 Chassis Intrustion Header
The server board includes a 2-pin chassis intrusion header which can be used when the chassis
is configured with a chassis intrusion switch. On the server board, this header is labeled CHAS
INTR. The header has the following pin-out.
