Appendix E: Management Engine Generated SEL Event Messages Intel® Server Board S2600CO Family TPS
Revision 1.0
Intel order number G42278-002
140
Appendix E: Management Engine Generated SEL Event
Messages
This appendix lists the OEM System Event Log message format of events generated by the
Management Engine (ME). This includes the definition of event data bytes 10-16 of the
Management Engine generated SEL records. For System Event Log format information, see the
Intelligent Platform Management Interface Specification, Version 2.0.
Table 74. Server Platform Services Firmware Health Event
Server Platform Services
Firmware Health Event
Request
Byte 1 - EvMRev
=04h (IPMI2.0 format)
Byte 2 – Sensor Type
=DCh (OEM)
Byte 3 – Sensor Number
=23 – Server Platform Services Firmware Health
Byte 4 – Event Dir | Event Type
[7] – Event Dir
=0 Assertion Event
[6-0] – Event Type
=75h (OEM)
Byte 5 – Event Data 1
[7,6]=10b – OEM code in byte 2
[5,4]=10b – OEM code in byte 3
[3..0] – Health Event Type
=00h –Firmware Status
Byte 6 – Event Data 2
=0 - Forced GPIO recovery. Recovery Image loaded due to MGPIO<n>
(default recovery pin is MGPIO1) pin asserted.
Repair action: Deassert MGPIO1 and reset the ME
=1 - Image execution failed. Recovery Image loaded because
operational image is corrupted. This may be either caused by Flash
device corruption or failed upgrade procedure.
Repair action: Either the Flash device must be replaced (if error is
persistent) or the upgrade procedure must be started again.
=2 - Flash erase error. Error during Flash erases procedure probably
due to Flash part corruption.
Repair action: The Flash device must be replaced.
=3 – Flash corrupted. Error while checking Flash consistency probably
due to Flash part corruption.
Repair action: The Flash device must be replaced (if error is
persistent).
=4 – Internal error. Error during firmware execution.
Repair action: FW Watchdog Timeout
Operational image shall be upgraded to other version or hardware
board repair is needed (if error is persistent).
=5..255 – Reserved
Byte 7 – Event Data 3
=<Extended error code. Should be used when reporting an error to the
support>
