Intel S2600CO Family User Manual

Intel® Server Board S2600CO Family TPS Appendix B: Compatiable Intel® Server Chassis
Revision 1.0
Intel order number G42278-002
115
Appendix B: Compatiable Intel
®
Server Chassis
Intel
®
Server Chassis P4000M Family is 4U pedestal, 25’’ length server chassis that is designed
to support Intel
®
Server Board S2600CO. It also provides a rackable feature.
A. 550-W Fixed Power supply
B. I/O Ports
C. Alternate RMM4 Knockout
D. PCI Add-in Board Slot Covers
E. AC Input Power Connector
F. Serial Port Knockout
G. A Kensington* Cable Lock Mounting Hole
H. Padlock Loop
I. Alternate RMM4 Knockout
J. Front Control Panel
K. 5.25’’ Peripheral Bays
L. CPU Zone System Fan (Fixed System Fan 2)
M. Fixed Hard Drive Carrier Tray
N. PCI Zone System Fan (Fixed System Fan 1)
O. PCI Card Retainer
Figure 29. Intel
®
Server Chassis P4308XXMFEN
