Intel® Server Board S2600CO Family TPS Functional Architecture Overview
Revision 1.0 41
Intel order number G42278-002
resources and is considered the secondary video device. The BIOS Setup utility provides
options to configure the feature as follows:
Table 12. Video mode
On-board Video
Enabled
Disabled
Dual Monitor Video
Enabled
Disabled
Shaded if on-board video is set to "Disabled"
3.4.3 Baseboard Management Controller
The server board utilizes the following features of the embedded baseboard management
controller.
 IPMI 2.0 Compliant
 400MHz 32-bit ARM9 processor with memory management unit (MMU)
 Two independent10/100/1000 Ethernet Controllers with Reduced Media Independent
Interface (RMII)/ Reduced Gigabit Media Independent Interface (RGMII) support
 DDR2/3 16-bit interface with up to 800 MHz operation
 16 10-bit ADCs
 Sixteen fan tachometers
 Eight Pulse Width Modulators (PWM)
 Chassis intrusion logic
 JTAG Master
 Eight I2C interfaces with master-slave and SMBus timeout support. All interfaces are
SMBus 2.0 compliant.
 Parallel general-purpose I/O Ports (16 direct, 32 shared)
 Serial general-purpose I/O Ports (80 in and 80 out)
 Three UARTs
 Platform Environmental Control Interface (PECI)
 Six general-purpose timers
 Interrupt controller
 Multiple Serial Peripheral Interface (SPI) flash interfaces
 NAND/Memory interface
 Sixteen mailbox registers for communication between the BMC and host
 LPC ROM interface
 BMC watchdog timer capability
 SD/MMC card controller with DMA support
 LED support with programmable blink rate controls on GPIOs
 Port 80h snooping capability
 Secondary Service Processor (SSP), which provides the HW capability of offloading time
critical processing tasks from the main ARM core.
