On-board Connector/Header Overview Intel® Server Board S2600CO Family TPS
Revision 1.0
Intel order number G42278-002
90
Pin
Signal Name
3
SMB_HSBP_3V3STBY_CLK
8.3.6 HDD LED Header
The server board includes a 2-pin hard drive activity LED header used with some SATA/SAS
controller add-in cards. On the server board, this header is labeled HDD LED. The header has
the following pin-out.
Table 38. Hard Drive Acitivity Header Pin-out (HDD_LED)
Pin
Signal Name
1
LED_HDD_ACT_N
2
TP_LED_HDD_ACT
8.3.7 Internal Type-A USB Connector
The server board includes one internal Type-A USB connector labeled USB_4. The following
table provides the pin-out for this connector.
Table 39. Internal Type-A USB2.0 Connector Pin-out (USB_4)
Pin
Signal Description
1
+5V
2
USB_N
3
USB_P
4
GND
8.3.8 Internal 2mm Low Profile eUSB SSD Connector
The server board includes one 10-pin 2mm low profile connector with an intended usage of
supporting low profile eUSB SSD devices. On the server board this connector is labeled
eUSB_SSD. The following table provides the pin-out for this connector.
Table 40. Internal eUSB Connector Pin-out (eUSB_SSD)
Pin
Signal Name
Pin
Signal Name
1
+5V
2
NC
3
USB_N
4
NC
5
USB_P
6
NC
7
GND
8
NC
10
LED#
8.4 Management and Security Connectors
8.4.1 RMM4_Lite Connector
A 7-pin Intel
®
RMM4 Lite Connector is included on the server board to support the optional
Intel
®
Remote Management Module 4. There is no support for third-party management cards on
this server board. On the server board this connector is labeled as RMM4_Lite. The following
table provides the pin-out for this connector.
