Functional Architecture Overview Intel® Server Board S2600CO Family TPS
40 Revision 1.0
Intel order number G42278-002
3.4.1.1 Keyboard and Mouse Support
The server board does not support PS/2 interface keyboards and mice. However, the system
BIOS recognizes USB specification-compliant keyboard and mice.
3.4.1.2 Wake-up Control
The super I/O contains functionality that allows various events to power on and power off the
system.
3.4.2 Graphics Controller and Video Support
The integrated graphics controller provides support for the following features as implemented on
the server board:
Integrated Graphics Core with 2D Hardware accelerator
DDR-3 memory interface with 16MB of memory allocated and reported for graphics
memory
High speed Integrated 24-bit RAMDAC
Single lane PCI-Express host interface running at Gen 1 speed
The integrated video controller supports all standard IBM VGA modes. The following table
shows the 2D modes supported for both CRT and LCD:
Table 11. Video Modes
** Video resolutions at 1600x1200 and higher are only supported through the
external video connector located on the rear I/O section of the server board.
Utilizing the optional front panel video connector may result in lower video
resolutions.
The server board provides one video interfaces. The video interface is accessed using a
standard 15-pin VGA connector found on the back edge of the server board.
The BIOS supports dual-video mode when an add-in video card is installed.
In the single mode (dual monitor video = disabled), the on-board video controller is disabled
when an add-in video card is detected.
In the dual mode (on-board video = enabled, dual monitor video = enabled), the on-board video
controller is enabled and is the primary video device. The add-in video card is allocated
