JR XP7202 User Manual

24
XP7202 Instruction Manual
1= 25%
2= 50%
3= 75%
H= High
Press the IncreaSe or DecreaSe keys to adjust the
throttle value of the selected throttle position.
NOTE
: For more information about setting up
throttle curves see Page 87.
Throttle Curve
Adjusting the Normal Throttle Curve
Adjustment of the throttle curves is similar to the pitch
curve adjustment described on the preceding page. Three
throttle curves are available: normal, stunt 1 and stunt 2.
All throttle curves have five adjustable points—low, 25%,
50%, 75% and high. Flight modes are located on the
3-position flight mode switch. The throttle curve is in the
normal mode when the Flight Mode switch is in the rear
position and the Throttle Hold switch is rearward.
With the power off, turn the transmitter on then press the
clear key to enter the main menu.
Press the Down and Select keys simultaneously to
enter the function mode.
Press the UP or Down key until THROTTLE CURVE
NORM appears on screen.
Press the Select key to select the stick position that you
wish to adjust the throttle.
L= Low
NOTE
: For more information about setting up pitch curves, see Page 89.
[THRO CURVE]
NORM
≥Point-L
51 51
0.0%
1 2 3 HL
IN OUT
Press and hold to enter Function Mode
Use to select
THROTTLE CURVE NORM
Use to change value of
selected stick position
Press to enter main menu
Use to select stick position
