XP7202 Instruction Manual
The XP7202 offers three (3) separate throttle curves
with five (5) adjustable points per curve. This function
allows you to customize the throttle curve and pitch curve
together to maximize engine performance at a particular
pitch setting. Once the throttle curves are established,
each can be activated in flight using the three (3) position
flight mode switch. The flight mode switch offers three (3)
selectable curves. N=Normal, 1=Stunt 1, 2=Stunt 2
The N, or Normal, position should be used for hovering.
Positions 1 and 2, or Stunt 1 and Stunt 2, should be used
for aerobatic maneuvers and forward flight.
NOTE
: The throttle trim and hovering throttle lever
are only operable when the flight mode switch is in
the Normal position. Thus, in the 1 or 2 positions,
these two functions have no effect.
Each of the five (5) positions of the throttle curve are
independently adjustable from 0 -100%. These five (5)
positions correspond to the position of the throttle stick.
The transmitter is factory preset to the throttle curve as
indicated by the solid line in the figure below. Individual
middle points can be activated and increased/decreased to
suit your specific needs.
Throttle Curve
