78
XP7202 Instruction Manual
List Modes
To enter the Function List mode, with the system on and
in any Function mode screen, press the UP and Select
keys simultaneously.
In either list mode, pressing the UP and Down keys will
move the cursor to the desired function. Then pressing the
Down
and Select key simultaneously will access the
selected function.
The list mode screens display all the functions onscreen,
allowing the access of any function without having to
scroll through each screen. Note that there are two list
modes: a System Setup list mode that displays all the
system setup functions and a Function list mode that
displays all the system programming functions.
To enter the System Setup List Mode, with the system
on and in any System Setup function, press the UP and
Select
keys simultaneously.
[FUNCTION LIST]
THRO HOLD
º
PI CURV ST1
º
PI CURV NOR
º
TH CURV ST2
º
TH CURV ST1
º
TH CURV NOR
◊DUAL RATE
º
TRAV ADJ.
º
SUB TRIM
º
REV SW.
º
EXPONENT.
SELECT key
UP and DOWN key
INCREASE and DECREASE key
CLEAR key
Normal Display
MODEL 1
CH 15
PPM
10.6V
72.09MHz
JR-PROPO
0:14:12
Transmitter Voltage
Graphic Battery Display
Modulation Type
Frequency
Integrated Timer
Model Type
Model Name
Channel Number
