XP7202 Instruction Manual
The Reverse Switch function allows electronic means of
reversing the servo’s throw. Servo reversing is available for
all seven channels.
Press the Down and Select keys simultaneously to
access the Function Mode
In Function Mode, use the UP or Down key to select the
REVERSE
screen.
Press the Select key to access the desired channel
Reverse Switch
To Access the Reverse Switch Mode
Press the IncreaSe or DecreaSe keys to reverse the
servo direction for that selected channel. The channels
available are:
THRO: Throttle
AILE: Aileron
ELEV: Elevator
RUDD: Rudder
GEAR: Retractable Landing Gear
FLAP: Flap
AUX2: AUX2
[REVERSING SW]
NORM
GEAR
≤
ch 1 2 3 4 5 6 7
REV.
Press to enter
Function Mode
Press to enter REVERSE
Press to select REV. or NORM
Press to select
desired channel
