63
XP7202 Instruction
Manual
•
The
UP
and
Down
keys
are
used to
select
the
programming function.
•
The
S
e
l
ec
t
key
is
used
to select
the
channel or
feature that
you
wish
to program.
•
The
In
crea
Se
or
DecreaSe
keys
are
used to
change the
values
of
the selected
programming
feature.
The XP7202
features
two
programming modes:
System Setup
Mode
and
Function Mode,
which
are
described as
follows:
General
Information
MODEL 1
CH 15
PPM
10.6V
72.09MHz
JR-PROPO
0:14:12
SELECT key
UP and
DOWN
key
INCREASE and
DECREASE
key
CLEAR key
Key
Input and
Display
Functions
62
64
