Keithley 2611B Reference Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. B / May 2013 7-159
Usage
tbl = QueryPulseConfig(tag)
tag
Numeric identifier to be assigned to the defined pulse train
tbl
Returned table
Details
Once a pulse train has been configured and assigned to a tag, it is often desirable to inspect the settings of this
preconfigured pulse train. The QueryPulseConfig() command can be used for this purpose.
This function returns a table that contains the settings associated with the tag input parameter.
Return values:
tostring()
A function that returns most settings in a string that is convenient for printing
tag
Identifying tag for this pulse train
smu
The SMU configured for pulsing
func
Pulse function:
smuX.OUTPUT_DCAMPS or
smu
X
.OUTPUT_DCVOLTS
bias
Pulse bias level
level
Pulse level for non sweeping pulses
start
Starting level for sweep pulses
stop
Ending level for sweep pulses
limit
Limit value
ton
On time in seconds
toff
Off time in seconds
points
The number of points in this pulse train
buf
Reference to the buffer that contains measurement data
sync_in
The sync_in digio line, if used
sync_out
The sync_out digio line, if used
sourcevalues
A table containing the source value for each point in the pulse train
