Bit Value Description
B0
Not used
Not applicable.
B1
status.measurement.voltage_limit.SMUA
Set bit indicates the enabled VLMT bit for the
SMU A measurement register is set.
Bit B1 decimal value: 2
Binary value: 0000 0010
B2
status.measurement.voltage_limit.SMUB
This bit is only available on Models
2602B/2604B/2612B/2614B/2634B/2636B. Set
bit indicates the enabled VLMT bit for the SMU
B measurement register is set.
Bit B2 decimal value: 4
Binary value: 0000 0100
B3-B15
Not used
Not applicable.
As an example, to set bit B1 of the measurement event voltage limit summary enable register, set
status.measurement.voltage_limit.enable = status.measurement.voltage_limit.SMUA.
In addition to the above constants, measurementRegister can be set to the decimal equivalent of the bit to
set. To set more than one bit of the register, set measurementRegister to the sum of their decimal weights.
For example, to set bits B1 and B2, set measurementRegister to 6 (which is the sum of 2 + 4).
Example
status.measurement.voltage_limit.enable =
status.measurement.voltage_limit.SMUA
Sets the SMUA bit of the
measurement event voltage limit
summary enable register using a
constant.
Also see
Measurement event registers (on page E-8)
status.node_enable
This attribute stores the system node enable register. This attribute is not available on the Models
2604B/2614B/2634B.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Status reset
Not saved
0
Usage
nodeEnableRegister = status.node_enable
status.node_enable = nodeEnableRegister
nodeEnableRegister
The status of the system node enable register; a zero (0) indicates no bits set (also
send 0 to clear all bits); other values indicate various bit settings
