Keithley 2611B Reference Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. B / May 2013 7-251
Also see
smuX.trigger.source.action (on page 7-246)
smuX.trigger.source.linearY() (on page 7-248)
smuX.trigger.source.listY() (on page 7-249)
Sweep operation (on page 3-20)
smuX.trigger.source.set()
This function sets the source event detector to the detected state.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
smuX.trigger.source.set()
X
Source-measure unit (SMU) channel (for example,
smua.trigger.source.set()
applies to SMU channel A)
Details
This function sets the source event detector to the detected state.
The SMU automatically clears all event detectors when the smuX.trigger.initiate() function is executed.
This function should be called after the sweep is initiated. If the event detectors are configured to clear
automatically because the smuX.trigger.autoclear attribute is set to smuX.ENABLE, make sure that
smuX.trigger.source.set() is issued after the SMU has entered the trigger layer.
Also see
smuX.trigger.arm.set() (on page 7-233)
smuX.trigger.autoclear (on page 7-235)
smuX.trigger.endpulse.set() (on page 7-237)
smuX.trigger.initiate() (on page 7-240)
smuX.trigger.measure.set() (on page 7-241)
Triggering (on page 3-32)
smuX.trigger.source.stimulus
This attribute defines which event causes the source event detector to enter the detected state.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Not saved
0
Usage
eventID = smuX.trigger.source.stimulus
smuX.trigger.source.stimulus = eventID
eventID
Set to the event that triggers the end pulse source off action
X
Source-measure (SMU) channel (for example,
smua.trigger.source.stimulus applies to SMU channel A)
