7: TSP command reference Series 2600B System SourceMeter® Instrument
7-276 2600BS-901-01 Rev. B / May 2013
Details
These attributes are used to read or write to the operation status digital I/O summary registers. Reading a status
register returns a value. The binary equivalent of the returned value indicates which register bits are set. The
least significant bit of the binary number is bit B0, and the most significant bit is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set contents (on
page E-1) and Enable and transition registers (on page E-19). The individual bits of this register are defined in
the following table.
Bit Value Description
status.operation.instrument.digio.TRIGGER_OVERRUN
status.operation.instrument.digio.TRGOVR
enabled bit in the
Operation Status Digital
I/O Overrun Register is set.
Bit B10 decimal value:
1,024
Binary value:
0100 0000 0010
In addition to the above constant, operationRegister can be set to the decimal equivalent of the bit to set.
Example
status.operation.instrument.digio.enable =
status.operation.instrument.digio.TRGOVR
Sets the TRGOVR bit of the
operation status digital I/O summary
enable register using a constant.
Also see
Operation Status Registers (on page E-9)
status.operation.instrument.digio.trigger_overrun.* (on page 7-276)
status.operation.instrument.digio.trigger_overrun.*
This attribute contains the operation status digital I/O overrun register set. This attribute is not available on the
Models 2604B/2614B/2634B.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.ptr (RW) Yes Status reset Not saved 32,766 (All bits set)
