7: TSP command reference Series 2600B System SourceMeter® Instrument
7-228 2600BS-901-01 Rev. B / May 2013
smuX.source.output
This attribute sets the source output state (on or off).
Type TSP-Link accessible Affected by Where saved Default value
Instrument reset
Usage
sourceOutput = smuX.source.output
smuX.source.output = sourceOutput
The source's output state setting; set to one of the following values:
0 or smuX.OUTPUT_OFF: Turns off the source output
1 or smuX.OUTPUT_ON: Turns on the source output
2 or smuX.OUTPUT_HIGH_Z
: Turns off the output in high Z mode (allows you to go
to high Z mode without first setting the smuX.source.offmode attribute to
X
Source-measure unit (SMU) channel (for example, smua.source.output applies
to SMU channel A)
Details
Reading this attribute returns the output state of the source. Setting this attribute switches the output of the
source on or off.
When the output is switched on, the SMU sources either voltage or current, as set by smuX.source.func.
Setting this attribute to smuX.OUTPUT_HIGH_Z causes the output to turn off and go to the High Z mode. If the
smuX.source.output is read after setting this attribute to smuX.OUTPUT_HIGH_Z, it returns 0.
Example
smua.source.output = smua.OUTPUT_ON
Turns on SMU channel A source
output.
Also see
DUT test connections (on page 2-48)
smuX.source.func (on page 7-221)
smuX.source.offmode (on page 7-226)
smuX.source.outputenableaction
This attribute controls output enable action of the source.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Instrument reset
Saved setup 0 (smuX.OE_NONE)
