Digital I/O mapping
The Models 2604B, 2614B, and 2634B do not have digital input/output lines.
When in Model 2400 emulation mode, digital I/O lines 1 through 9 are used to emulate different
Model 2400 lines through the digital I/O port (see Digital I/O port (on page 3-83
)). The following table
shows the mapping.
Model 2400 line DB-25 connector pin
Digital output 4 (or EOT, /EOT, BUSY, /BUSY)
SOT 9
Ground 15-21*
+5 V 23*
Output enable (OE) or Interlock (INT)**
** See Port configuration (on page 3-83) for information on pin 24.
