Series 3700A System Switch/Multimeter Reference Manual Section 11: TSP command reference
3700AS-901-01 Rev. D/June 2018 11-123
Trigger event ID
Description
channel.trigger[N].EVENT_ID
A channel trigger event starts the scan.
digio.trigger[N].EVENT_ID
An edge (either rising, falling, or either based on the
configuration of the line) on the digital input line.
display.trigger.EVENT_ID
The trigger key on the front panel is pressed.
dmm.trigger.EVENT_LIMIT1_HIGH
A DMM trigger event that indicates a measurement has exceed
the high limit value on limit 1.
dmm.trigger.EVENT_LIMIT1_LOW
A DMM trigger event that indicates a measurement has exceed
the low limit value on limit 1.
dmm.trigger.EVENT_LIMIT2_HIGH
A DMM trigger event that indicates a measurement has exceed
the high limit value on limit 2.
dmm.trigger.EVENT_LIMIT2_LOW
A DMM trigger event that indicates a measurement has exceed
the low limit value on limit 2.
trigger.EVENT_ID
A *trg message on the active command interface. If GPIB is the
active command interface, a GET message also generates this
event.
trigger.blender[N].EVENT_ID
A combination of events has occurred.
trigger.timer[N].EVENT_ID
A delay expired.
tsplink.trigger[N].EVENT_ID
An edge (either rising, falling, or either based on the
configuration of the line) on the TSP-Link trigger line.
lan.trigger[N].EVENT_ID
A LAN trigger event has occurred.
scan.trigger.EVENT_SCAN_READY
Scan ready event.
scan.trigger.EVENT_SCAN_START
Scan start event.
scan.trigger.EVENT_CHANNEL_READY
Channel ready event.
scan.trigger.EVENT_MEASURE_COMP
Measure complete event.
scan.trigger.EVENT_SEQUENCE_COMP
Sequence complete event.
scan.trigger.EVENT_SCAN_COMP
Scan complete event.
scan.trigger.EVENT_IDLE
Idle event.
schedule.alarm[N].EVENT_ID
A scan starts when alarm N fires.
Example 1
digio.trigger[3].stimulus = 0
Clear the trigger stimulus of digital I/O line 3.
Example 2
digio.trigger[3].stimulus = scan.trigger.EVENT_CHANNEL_READY
Set the trigger stimulus of digital I/O line 3 to be the channel ready event during a scan.
Also see
digio.trigger[N].assert() (on page 11-116)
digio.trigger[N].clear() (on page 11-117)
digio.trigger[N].reset() (on page 11-121)
