Keithley 3720-ST User Manual

Section 11: TSP command reference Series 3700A System Switch/Multimeter Reference Manual
11-404 3700AS-901-01 Rev. D/June 2018
As an example, to set bit B1 of the system summary 5 enable register, set
status.system5.enable = status.system5.NODE57.
In addition to the above constants, enableRegister can be set to the numeric equivalent of the bit
to set. To set more than one bit of the register, set enableRegister to the sum of their decimal
weights. For example, to set bits B1 and B4, set enableRegister to 18 (which is the sum of 2 +
16).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example 1
enableRegister = status.system5.NODE57 +
status.system5.NODE60
status.system2.enable = enableRegister
Uses constants to set bits B1 and B4 of
the system summary 5 enable register.
Example 2
-- decimal 18 = binary 0000 0000 0001 0010
enableRegister = 18
status.system5.enable = enableRegister
Uses a decimal value to set bits B1 and
B4 of the system summary 5 enable
register.
Also see
status.system4.* (on page 11-400)
System summary bit (System register) (on page C-5)
timer.measure.t()
This function measures the elapsed time since the timer was last reset.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
time = timer.measure.t()
time
The elapsed time in seconds (1 µs resolution)
