109
8
8
Maintenance Light bulbs
the socket align with the slots on
the assembly.
3. Remove the bulb from bulb-
socket by pulling it out.
4. Insert a new bulb by inserting it
into the bulb-socket.
5. Install the socket in the assembly
by aligning the tabs on the socket
with the slots in the assembly.
Push the socket into the assem
-
bly and turn the socket clockwise.
6. Align the lens cover tabs with the
lamp housing notches and snap
the lens into place.
Map lamp (Bulb type) bulb replace
-
ment
Prior to working on the Interior
lamps, ensure that the ä³–OFFä³— button
is depressed to avoid burning your
fingers or receiving an electric
shock.
1. Using a flat-blade screwdriver,
gently pry the lens cover from
lamp housing.
2. Remove the bulb by pulling it
straight out.
3. Install a new bulb in the socket.
4. Align the lens cover tabs with the
lamp housing notches and snap
the lens into place.
Be careful not to dirty or damage
the lens, lens tab, and plastic hous
-
ings.
Vanity mirror lamp (Bulb type) bulb
replacement
Prior to working on the Interior
lamps, ensure that the ä³–OFFä³— button
is depressed to avoid burning your
fingers or receiving an electric
shock.
