3.
Remove the bolts (1), and remove the cover (2).
4.
Remove mud and dirt around the breather (3).
5.
Remove the breather (3).
Take care to prevent entry of dusts through the mounting
section of the breather.
6.
Remove the bolt (4) of breather (3).
7.
Remove the cover (5).
8.
Rinse the breather (6) in clean diesel fuel or flushing oil,
and remove the dirt inside.
9.
Install the breather element (6).
10.
Install the cover (5) and bolt (4).
11.
Install the breather (3).
12.
Install the cover (2) with bolts (1).
13.
Remove the body pivot pin.
14.
Lower the dump body.
METHOD FOR CLEANING STEERING AND HOIST OIL TANK BREATHER
WARNING
Immediately after the engine is stopped, its parts and oil are still very hot and may cause burn injury.
Wait for the temperature to go down, and then start the work.
1.
Remove mud and dirt around the breather.
2.
Remove the breather.
Take care to prevent entry of dusts through the mounting
section of the breather.
MAINTENANCE PROCEDURE MAINTENANCE
4-44
