HANDLE KOMATSU TRACTION CONTROL SYSTEM
(KTCS)
WARNING
• KTCS is enabled when “KTCS Setting” is set to "ON".
• When the system cannot be properly controlled due to a trouble in the system, the machine monitor
displays an action level and the system may stop operation depending on the failure condition.
• The machine may not travel safely on an extremely slippery road or on a steep slope even if the
KTCS operates.
• If a wheel is stuck in the ground and the machine cannot escape while the KTCS operates, pull out
the machine with a bulldozer, etc.
KTCS is a system to prevent the drive wheels from slipping caused by excessive torque and improves starting
and traveling ability on the soft or slippery ground.
OPERATION OF KTCS
The KTCS is ready to start the control when “KTCS Setting” is
“ON”.
When the KTCS detects the rear wheel slipping, the KTCS
starts the control and the KTCS pilot lamp lights up.
METHOD FOR OPERATING MACHINE WHEN TIRES ARE STUCK IN
GROUND
If any wheel is stuck, operate the KTCS.
If it is impossible to get the machine out even when repeating the procedure below, use a bulldozer and such to
tow the machine out.
1.
Check that “KTCS Setting” is “ON”.
When “KTCS Setting” is “ON”, the KTCS operates automatically.
2.
Set the gear shift lever to the position 6 and increase the engine speed.
3.
Release the accelerator pedal and brake pedal.
4.
Set the gear shift lever to the position R and increase the engine speed.
5.
Repeat the steps 1 to 4 to move the machine backward and forward until it can escape.
HANDLE KOMATSU TRACTION CONTROL SYSTEM (KTCS) ATTACHMENTS AND OPTIONS
6-16
