User's Guide
- 45 -
5. From the printer control panel, set the paper size and paper type in the Paper menu to match the
paper or specialty media loaded in the multipurpose feeder.
Linking and unlinking trays
The printer links trays when the specified paper size and type are the same. When a linked tray becomes
empty, paper feeds from the next linked tray. To prevent trays from linking, assign a unique custom paper
type name.
Linking and unlinking trays
Using the Embedded Web Server
1. Open a Web browser, and then type the printer IP address in the address field.
Notes:
- View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address
appears as four sets of numbers separated by periods, such as 123.123.123.123.
- If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2. Click Settings >Paper Menu.
3. Change the tray settings to specify the paper size and type for the tray.
- To link trays, make sure the paper size and type for the tray match with that of the other tray.
- To unlink trays, make sure the paper size or type for the tray does not match with that of the other
tray.
4. Click Submit.
Using the printer settings on the computer
Depending on your operating system, access the Paper menu using the Local Printer Settings Utility or
Printer Settings.
Note: You can also specify the paper size and type for the tray using the printer control panel. For more
information, see
Setting the paper size and type.
Warning—Potential Damage: Paper loaded in the tray should match the paper type name assigned in
the printer. The temperature of the fuser varies according to the specified paper type. Printing issues may
occur if settings are not properly configured.
