User's Guide
- 54 -
550-sheet tray
176 x 250 mm (6.9 x 9.8 in.)
229 x 356 mm (9 x 14 in.)
This size setting formats the page for 216 x 356 mm (8.5 x 14 in.) unless the size is specified by the software
application.
2
Universal is supported in the standard tray only if the paper size is at least 105 x 148 mm (4.1 x 5.8 in.). Universal is
supported in the optional 250- or 550-sheet tray only if the paper size is at least 148 x 210 mm (5.8 x 8.3 in.).
Universal is supported in duplex mode only if the width is at least 210 mm (8.3 in.) and the length is at least 279 mm
(11 in.). The smallest supported Universal size is supported only in the multipurpose feeder.
3
Only long edge feeding is non-supported.
Supported paper types and weights
The standard tray supports 60–90-g/m
2
(16–24-lb) paper weights. The optional tray supports 60–120-
g/m
2
(16–32-lb) paper weights. The multipurpose feeder supports 60–163-g/m
2
(16–43-lb) paper weights.
Paper labels
Bond
