PERIODIC SERVICE96
1. To slow charge the battery, connect the battery
positive terminal to the charger positive terminal and
the negative to the negative, then recharge in the
standard fashion.
2. A boost charge is only for emergencies. It will partially
charge the battery at a high rate and in a short time.
When using a boost-charged battery, it is necessary to
recharge the battery as early as possible.
Failure to do this will shorten the battery's service life.
3. The battery is charged if the indicator display turns
green from black.
4. When exchanging an old battery for a new one, a
battery of equal specification.
C Direction for Storage
1. When storing the machine for long periods of time,
remove the battery from machine, adjust the
electrolyte to the proper level and store in a dry place
out of direct sunlight.
2. The battery self-discharges while it is stored.
Recharge it once every three months in hot seasons
and once every six months in cold seasons.
EVERY 250 HOURS SERVICE
Perform inspection and servicing for every 50 hours of
operation at the same time.
BGrease fittings
To avoid serious personal injury or death:
A Keep clear of articulation joint during service
work.
To avoid personal injury or death:
A Before greasing, always stop the engine, lower
the bucket and attachment to the ground,
release the hydraulic pressure in the hydraulic
system by operating the control levers. lock all
control levers in neutral, and remove the key.
A Always remove the bucket and attachment and
use the lift arm support when servicing the
machine with the loader lift arms raised.
C Greasing the propeller shaft
Apply grease to the universal joints and shaft at three
grease fittings.
(1) Battery
Battery Type Volts (V) Capacity
59533 12 95 (at 20H.R(A.H))
Battery Type
Reserve
Capacity
(min)
Cold
Cranking
Amps
Normal
Charging
Rate (A)
59533 165 720 6.5
