27CHECKS BEFORE START
BAuxiliary Port Lever Lock
To avoid personal injury or death:
A When dismounting the machine or when
servicing the machine, be sure to stop the
engine, lower the bucket and the attachment to
the ground, release the hydraulic pressure in
the hydraulic system by operating control
levers. Lock all control levers in neutral, and
remove the key.
A In case of the auxiliary port lever is used for the
hydraulic quick coupler, always lock the
auxiliary port lever after installing front
attachment (bucket etc.) to the hydraulic quick
coupler. If the machine is operated without the
lock, it causes sever injury or death.
This lock is used to lock the auxiliary port lever. With the
auxiliary port lever in neutral, forward or backward
position, operate the lock.
[R530]
CABIN TYPE MACHINE
BFront Wiper / Washer Switch
Before moving the windscreen wiper, make sure the
starter key is at the "RUN" position and then turn on the
windscreen wiper switch.
Position 0: The wiper is in neutral.
Position : The wiper moves at regular intervals.
Position I: The wiper moves at normal speed.
Push the ring toward the steering wheel, and the washer
system gets started.
A Do not activate the washer switch if the tank for the
cleaning fluid is empty; the pump can be damaged.
A Do not activate the wiper switch if the window is dry. In
this case, make sure that cleaning fluid is applied to
the window pane before activating the wiper.
A In frosty conditions, make sure that the wiper blade is
not frozen to the glass before switching-on. The motor
can be damaged if the wiper system is used under
such conditions.
(1) Front wiper / washer switch (A) "Position "
(B) "Position 0"
(C) "Position I"
