OPERATION OF THE MACHINE48
[R630]
SELECTION OF THE DRIVING MODE
This machine has 4-type driving mode.
According to the type of job or your operating style,
choose the best mode.
C Normal mode (N mode)
This mode is usually intended for general works. The
traveling force and the digging force are well balanced for
high performance. Normal mode is best suited for V shape
loading, loading and carrying, sand/gravel gathering and
similar jobs.
C Power mode (P mode)
The mode is used for digging and similar works that
require greater traction force. In other words, the mode is
highly applicable for excavating, piling, etc.
C ECO mode (E mode)
This mode is suitable for light-duty jobs such as material
handling. With the engine rpm kept at low level, better fuel
economy is achieved. The machine proves itself in
traveling with any handling material. Even in the Eco
mode, for example, the heavier the traveling load
becomes on slopes, the higher the engine speed rises. In
this way, the machine speed is kept at constant level.
C Attachment mode (ATT mode)
The ATT mode proves best with attachments, like
sweepers and mowers, which need enough hydraulic flow
but low traveling speed. In this mode, the hydraulic flow
rate and traveling speed can be independently controlled.
Turn on the engine speed (AUX flow) control dial on the
right side of the operator’s seat, and the engine rpm
(namely, hydraulic flow rate) becomes adjustable. Using
the speed control button, the traveling speed is
presettable in 5 steps: 1.5 km/h (0.93 mph)., 2.0 km/h
(1.24 mph)., 3.0 km/h (1.86 mph)., 4.0 km/h (2.48 mph).
and 4.6 km/h (2.85 mph) at the max. engine rpm. Speeds
from a start to maximum can be controlled with the
accelerator pedal.
A Engine speed (AUX flow) control dial is available in
case of only ATT mode.
(1) Engine speed (AUX flow) control dial (A) Min.
(B) Max.
