Reference Information 8-5
Paper Size and Priority Feed Chart (Inch
version)
If the drawers do not contain paper that is of a size and orientation
exactly the same as that of the received documents, the FAX will
automatically select the most appropriate paper for print out. The
following chart indicates the order of priority for paper selection in such a
case.
Notes for this Chart
• The abbreviations in the chart above refer to the following paper
sizes:
ST: 5
1/2 ×81/2" [width-wise]
STR: 5
1/2 ×81/2" [length-wise]
LT: 8
1/2 × 11" [width-wise]
LTR: 8
1/2 × 11" [length-wise]
LG: 8
1/2 ×14"
LD: 11 × 17"
• The top edge of the paper in these illustrations indicates the
direction of feed for transmission or print out.
• If the same size of paper is set in more than one location, the upper
drawer will have priority for paper feed.
Received Document Size
Order of Selection
Paper in Drawers
1
a
2
aab
3
aa
4
a
5
a
a. Indicates that the Rotate Received Data function will be used.
b. When the image of received documents is automatically reduced to fit onto the paper, 8
1/2 × 14" size images will
be reduced to fit onto 8
1/2 × 11" [length-wise] size paper.
: Indicates that a received page will be split and printed onto 2 or more separate sheets of paper.
ST LTR LT LG LT
STR LTR LT LG LD
LTR
LT LTR LTR
LT
LG LG
LG
LD
LTR
LT LD LD
LTR
LD
STR LT
