Lenze ECSEM Series User Manual

Commissioning
Setting of the feedback system for position and speed control
Resolver as position and speed encoder
6

110
EDBCSXM064 EN 11.0
6.7.1 Resolver as position and speed encoder
If a resolver is connected to X7 and used as a position and speed encoder, no settings are
necessary.
Lenze setting:
ƒ Resolver as position encoder: C0490 = 0
ƒ Resolver as speed encoder: C0495 = 0
Codes for feedback system selection
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
[C0490] Feedback pos 0
Selection of feedback system for
positioning control
 109
0 Resolver at X7 Standard setting
1 TTL encoder at X8
l Sets C0419 = 0 ("Common") if
a different encoder type as
under C0419 is set here.
2 SinCos encoder at X8
3 Absolute value encoder (single−turn) at
X8
4 Absolute value encoder (multi−turn) at
X8
[C0495] Feedback n 0
Selection of feedback system for
speed control
 109
0 Resolver at X7 Standard setting
1 TTL encoder at X8
l Sets C0419 = 0 ("Common") if
a different encoder type as
under C0419 is set here.
2 SinCos encoder at X8
3 Absolute value encoder (single−turn) at
X8
4 Absolute value encoder (multi−turn) at
X8
