Monitoring functions
Fault responses
9
220
EDBCSXM064 EN 11.0
9.1 Fault responses
Response ð Consequence
Display
Keypad XT
RDY IMP Fail
TRIP o n n
TRIP active: ð The power outputs U, V, W are switched to high resistance.
ð The drive is coasting (no control).
TRIP reset: ð The drive decelerates to its setpoint within the set deceleration
times.
Message
Danger!
The drive restarts automatically if the message is removed.
o n n
Message active: ð The power outputs U, V, W are switched to high resistance.
£ 0.5 s ð The drive is coasting (no control).
> 0.5 s ð The drive is coasting (due to internal controller inhibit). If
necessary, restart program.
Message reset: ð The drive runs to its setpoint with the maximum torque.
FAIL−QSP
ð The drive is decelerated to standstill within the quick stop
deceleration time (C0105).
˘ ˘ n
Warning
STOP!
The drive can be destroyed due to deactivated monitoring
functions.
n o n
ð The failure merely is displayed, the drive runs on in a controlled
manner.
Off STOP!
The drive can be destroyed due to deactivated monitoring
functions.
˘ ˘ ˘
ð There is no response to the failure.
o = off n = on
Responses ( 220) of monitoring functions can be parameterised partly via codes ˘ in the
GDC parameter menu under Monitoring.
