Monitoring functions
Configuring monitoring functions
Monitoring of max. system speed (NMAX)
9

250
EDBCSXM064 EN 11.0
9.3.19 Monitoring of max. system speed (NMAX)
Fault message Monitoring function System variable
Possible response
TRIP Messag
e
Warnin
g
Off
200 NMAX Max. system speed exceeded MCTRL_bNmaxFault_b ·
· Default setting
üSetting possible
The monitoring function responds if the current speed exceeds the max. system speed or
twice the value of C0011 (n
max
).
 Stop!
ƒ With regard to active loads (e. g. hoists), pay attention to the fact that the
drive in this case operates without torque. Specific on−site measures are
required!
ƒ If the actual speed value encoder fails, it is not provided that this monitoring
will be activated.
The max. system speed can be set via C0596.
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0596 NMAX limit 5500
Maximum system speed
 250
0 {1 rpm} 16000
