Preface and general information
About these Operating Instructions
Code descriptions
1
13
EDBCSXM064 EN 11.0
1.1.2 Code descriptions
Lenze codes are described in the form of tables with the following structure:
Column Abbreviation Meaning
No.
Cxxxx
Code no. Cxxxx
1 Subcode 1 of Cxxxx
2 Subcode 2 of Cxxxx
Cxxxx Changed input value of the code or subcode is accepted after pressing
.
[Cxxxx] Changed input value of the code or subcode is accepted after pressing
when the controller is inhibited.
Name LCD display of the keypad XT EMZ9371BC
Lenze/{Appl.}
x Lenze setting:
l Value at the time of delivery or after loading the Lenze setting using
C0002.
{xxx...} Different application initialisation value
l Value at the time of delivery
l After loading the Lenze setting using C0002, the application
initialisation value is overwritten with the Lenze setting.
l The application initialisation values can be restored by loading the
application software with "Global Drive Loader" (GDL).
à The "Important" column contains further information
Selection 1 {%} 99 minimum value {unit}maximum value
IMPORTANT Short code description
Example
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0003 Par save 0
Non−volatile saving of parameter
set
0 No response
1 Save parameter set
C1192 Selection of resistance
characteristic for PTC
1 Char.: OHM 1000
{0}
0 {1 W} 30000 PTC characteristic:
resistance R1 at T1
2 Char.: OHM 2225 PTC characteristic:
resistance R2 at T2
