Monitoring functions
Configuring monitoring functions
Current load of controller (I x t monitoring: OC5, OC7)
9
234
EDBCSXM064 EN 11.0
9.3.9 Current load of controller (I x t monitoring: OC5, OC7)
Fault message Monitoring function System variable
Possible response
TRIP Messag
e
Warnin
g
Off
015 OC5 I x t overload MCTRL_bIxtOverload_b ·
· Default setting
üSetting possible
The I x t monitoring function monitors the current load of the axis module. The monitoring
function is set so that operation
ƒ is permanently possible with a device output current = I
r
.
ƒ is possible for ££ 30 s with a device output current ££ 1.5 x I
r
.
The overload protection of the axis module can be set with thresholds:
ƒ adjustable threshold (OC7) via C0123
ƒ fixed threshold (OC5) = 100 %
After an overcurrent phase, you can calculate with a recovery phase of 120 s. For a more
precise consideration, see the overcurrent characteristic and the value 3 x
t
axis
module
( 235).
The response to exceeding the adjustable threshold can be defined under C0604.
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0123 OC7 limit 90
Threshold for I x t warning (axis
module)
228
0 {1 %} 100 C0064 > C0123 ð fault message
OC7 (C0604)
C0604 MONIT OC7 2
Fault response − monitoring of
Ixt device utilisation.
Ixt threshold can be set under
C0123.
228
0 TRIP
2 Warning
3 Off
