Technical data
Operation with rated power (normal operation)
Rated data for 400 V mains voltage
3
3.2
3.2.1

3.2-3
EDSVF9333V EN 3.0-06/2005
Typical motor power
Three-phase asynchronous motor
(4-pol.)
P
r
[kW] 30 45 55 75 90
P
r
[hp] 40 60 74 100 120
9300 vector type EVF9329 EVF9330 EVF9331 EVF9332 EVF9333
Mains voltage U
mains
[V] 3/PE AC 320 V - 0 % ... 528 V + 0 % ; 45 Hz - 0 % ... 65 Hz + 0 %
Alternative DC supply U
DC
[V] DC 460 V - 0 % ... 620 V + 0 %
Data for operation on 3/PE AC 400 V or DC 565 V
Rated mains current
Without mains choke/mains filter I
mains
[A] – – – – –
With mains choke/mains filter I
mains
[A] 55.0 80.0 100 135 165
Output power U, V,
W with switching
frequency
2and4kHz
S
N
[kVA] 41.6 61.7 76.2 103.9 131.2
8kHz
S
N
[kVA] 41.6 61.7 76.2 103.9 124.7
Output power +U
DC
,-U
DC
1)
P
DC
[kW] 0.0 5.1 0.0 28.1 40.6
Rated output current
with switching
frequency
2and4kHz I
N
[A]
4)
59.0 89.0 110 150 180
8kHz I
r
[A] 59.0 89.0 110 147 147
8kHzsin I
r
[A] 47.0 59.0 76.0 92.0 100
16 kHz I
r
[A] 35.0 46.0 52.0 58.0 63.0
8/2 kHz
3)
I
r
[A] 59.0 89.0 110 150 180
Max. permissible
output current for 60
s at a switching
frequency
2) of
2and4kHz I
max
[A] 89.0 134 165 225 270
8kHz I
max
[A] 89.0 134 165 221 221
8kHzsin I
max
[A] 70.0 88.0 114 138 150
16 kHz I
max
[A] 53.0 69.0 78.0 87.0 94.0
8/2 kHz
3)
I
max
[A] 89.0 134 165 225 270
Output voltage
With mains choke/mains filter U
M
[V] 3~0...approx.94%U
mains
/ 0 ... 600 Hz
Power loss (operation with I
N
) P
v
[W] 810 1100 1470 1960 2400
Required mains choke Type
ELN3-0055H055 ELN3-0038H085 ELN3-0027H105 ELN3-0022H130 ELN3-0017H170
Dimensions
H [mm] 350 510 591 680 680
b [mm] 250 340 340 450 450
T [mm] 250 285 285 285 285
Earth [kg] 18.0 36.0 38.0 70.0 70.0
Bold print = Lenze setting
1)
Power supplied by the DC bus when operating with power-adapted motor
2)
Currents for periodic load change: 60 s of overcurrent time with I
max
and 120 s of base load time
with 75 % I
N
3)
Power-optimised operation with automatic switching frequency reduction. When the max.
permissible output c urrent is exceeded, the switching frequency is reduced to 2 kHz.
4)
Possible for some types in case of other operating conditions: Operation with increased rated
output current at the same load change (see chapter ”Operation with increased rated power”)
