Configuration
Code table
8
8.3
8.3-30
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0517
0.00 {0.01 } 1999.00
z Theusermenucontainsinthe
Lenze setting the most
important codes for
commissioning the operating
mode ”V/f characteristic
control
z With an active password
protection only the codes
entered in C0517 can be freely
accessed
z Enter the numbers of the
required codes in the subcodes
z The input is done in the format
xxx.yy
– xxx: Code number
– yy: Subcode number
z It is not checked whether the
entered code exists.
1 USER MENU 51.00 Actual speed value (MCTRL-NACT)
2 USER MENU 54.00 Actual motor current (MCTRL-IACT)
3 USER MENU 56.00 Torque setpoint (MCTRL-MSET2)
4 USER MENU 64.00 Device utilisation I×t
5 USER MENU 183.00 Diagnostics
6 USER MENU 168.01 History buffer
7 USER MENU 39.01 JOG-setpoints 1 (NSET)
8 USER MENU 86.00 Motor type selection
9 USER MENU 148.00 Identifying motor parameters
10 USER MENU 22.00 I
max
limit in motor mode
11 USER MENU 23.00 I
max
limit in generator mode
12 USER MENU 11.00 Maximum speed N
max
13 USER MENU 12.00 Acceleration time T
ir
main setpoint
14 USER MENU 13.00 Deceleration time T
if
main setpoint
15 USER MENU 16.00 U
min
boost
16 USER MENU 70.00 Gain V
p
speed controller
17 USER MENU 71.00 Integral-action time T
n
speed controller
18 USER MENU 75.00 Gain V
p
current controller
19 USER MENU 76.00 Integral-action time T
n
current controller
20 USER MENU 142.00 Starting condition
21 USER MENU 92.00 Motor stator inductance
22 USER MENU 36.00 DC braking current
23 USER MENU 93.00 Controller identification
24 USER MENU 99.00 Software version
... ... 0 Not assigned
31 USER MENU 94.00 Password
32 USER MENU 3.00 Save parameter set
